Description
These devices offer low offset and long-term stability by means of a low-noise, chopperless, bipolar-input-transistor amplifier circuit. For most applications, external components are not requiredfor offset nulling and frequency compensation. The true differential input, with a wide input-voltage range and outstanding common-mode rejection, provides maximum flexibility and performance in high-noiseenvironments and in noninverting applications. Lowbias currents and extremely high input impedancesare maintained over the entire temperature range.
Features
·Low Noise
·No External Components Required
·Replace Chopper Amplifiers at a Lower Cost
·Wide Input-Voltage Range:0 to ±14 V(Typ)
·Wide Supply-Voltage Range:±3V to±18V
Applications
·Wireless Base Station Control Circuits
·Optical Network Control Circuits
·Instrumentation
·Sensors and Controls
·Precision Filters
Feature
- Low Noise
- No External Components Required
- Replace Chopper Amplifiers at a Lower Cost
- Wide Input-Voltage Range: 0 to ±14 V (Typ)
- Wide Supply-Voltage Range: ±3 V to ±18 V
These devices offer low offset and long-term stability by means of a low-noise, chopperless,bipolar-input-transistor amplifier circuit. For most applications, external components are not required for offset nulling and frequency compensation. The true differential input, with a wide input-voltage range and outstanding common-mode rejection, provides maximum flexibility and performance in high-noise environments and in noninverting applications. Low bias currents and extremely high input impedances are maintained over the entire temperature range.
